Interior Valve Bodies As Well As The Stem And Ball Are Individually Lined With PFA Or PVDF/FEP

Ball Is Fully Encapsulated In PFA/FEP. Ceramic Balls Are Also Available Which Are Interchangeable

Anti-Blow Out Stem Assembly For Preventing Stem Blow Out Even When Top Gear Is Disassembled

Short Pattern Face To Face Dimension In Accordance With ANSI B16.10 And ANSI B 16.5, 150 Lbs.(Flange Dimension) - Facilitating Replacement Of Fully Lined Or Sleeved Plug Valves With Horizon Lined Ball Valves Without Altering Existing Pipework

Valves Supplied With Anti-Static Devices For Protection Against Potentially Dangerous Electrostatic Discharge

Free Floating Ball Valve Principle Ensures The Ball Seals Against The Downstream Seat Ring Giving A Positive Sealing Force Even When Line Pressure Is Low

All Inherent Design Features Of A Conventional Ball Valve Such As Low Torque, Quarter-Turn Operation, Bubble Tight Shut Off And A Minimum Pressure Drop

Valves Have Been Satisfactorily Tested For Helium Leak Test To Meet With ASME Sec V Article 10; Witnessed By Independent Inspection Agency(TUV)

Valve Bodies Available In Ductile Iron Material - ASTM A395 (60-40-18) & In CAST Carbon Steel ASTM A216WCB

Valve Bodies Can Be Supplied In All Grades Of Stainless Steel Material As Per Request

Requires Significantly Lower Torque For Operation Than Equivalent Plug Valves

Easy Manual Operation And Considerably Low Actual Figures
